Automatic Coconut Peeler Machine
The Automatic Coconut Peeler Machine is an innovative machine that removes the hard outer layer of green coconuts, leaving only the white meat and water. This tool is designed to be compact, portable, and easy to operate, making it the perfect solution for small-scale and large-scale coconut processing facilities.
Working principle
The Automatic Coconut Peeler Machine is designed to peel the outer layer of the coconut, leaving the inner flesh intact. The machine consists of a rotating drum, a conveyor belt, and a peeling blade.
The coconuts are fed into the machine through the conveyor belt, which carries them towards the peeling blade. As the drum rotates, the blade peels the outer layer of the coconut, and the flesh falls into the collection tray.
The Automatic Coconut Peeler Machine works by taking the coconut's hard outer layer off by using a specially designed blade and rotating rollers. The machine is operated by electricity and can adjust the peeling thickness to ensure that the white meat is not damaged during the peeling process. The Green Coconut Peeler only requires one person to operate, while others can sort, wash, and package the coconuts for sale.
How to operate
1. First, ensure that the machine is properly installed and connected to a power source.
2. Turn on the machine and allow it to warm up for a few minutes.
3. Adjust the speed of the drum according to the size of the coconuts.
4. Place the coconuts on the conveyor belt, ensuring that they are evenly spaced and not touching each other.
5. The machine will automatically peel the coconuts and discharge the peeled flesh into the collection tray.
6. Once the peeling is complete, switch off the machine and dispose of the shells.
7. Collect the peeled coconuts in a tray, and continue with the peeling process.
8. After peeling, wash the coconuts once again and sort them according to their sizes and quality.
Technical parameters
|
Model |
HT-QYZ1 |
|
Power supply |
AC220±10%V, 50Hz |
|
Rated rower |
0.8kW |
|
Rated revolution |
181±10rpm |
|
Rated torque |
35N·m |
|
Range of use |
120-240mm |
|
Peeling range |
100-160mm |
|
Operating pressure |
70-100psi(5-7bar) |
|
Operating fluid |
Through 40μm filtered compressed air |
|
Gas consumption |
0.05-0.06m³/min |
|
Cutter material |
440c |
|
Working temperature |
0℃-40℃ |
|
Working relative humidity |
≤80% |
|
Noise |
≤50dB(A) |
|
Overall size(W×D×H) |
300mm×420mm×870mm |
|
Net weight |
50.5kg |
Product Pictures
