Avocado Oil Production Line

The application of avocado oil extraction production line has revolutionized the process of extracting avocado oil. The modern technology used in the production line has made the extraction process faster, more efficient, and cost-effective. The production line ensures that the extracted oil is of high quality, pure, and free from impurities and contaminants. Operating the production line is easy, and the output is highly productive.
Send Inquiry
Product Introduction

Avocado Oil Production Line is used for extracting oil from avocado fruits. The extracted oil is used for culinary, cosmetic, and medicinal purposes. The oil is rich in mono-saturated fats and antioxidants, which makes it a healthier alternative to other cooking oils. Avocado oil is also used in the production of cosmetic products such as body lotions and soaps. The oil is known for its moisturizing and anti-aging properties, making it an excellent addition to skincare products.



Advantages



The use of an Avocado Oil Production Line has several advantages over traditional extraction methods. Firstly, the production line uses modern technology, which makes the extraction process more efficient and faster. The production line allows for the processing of large quantities of avocado fruits in a shorter time, reducing the production time and increasing output. Secondly, the production line ensures the quality of the extracted oil. The equipment used in the production line is designed to extract high-quality and pure avocado oil, free from impurities and contaminants. Thirdly, the production line is easy to operate and maintain, reducing the need for skilled labor and increasing productivity.



Working principle



The Avocado Oil Production Line works by crushing and pressing the avocado fruits to extract the oil. The fruits are first washed to remove dirt and debris. They are then cut into small pieces using a slicer or a knife. The crushed pieces are then placed in a hydraulic press, which applies pressure to extract the oil. The oil is then separated from the pulp and collected into containers. The production line uses modern technology, which includes a steam boiler, heater, conveyor, and a centrifuge. The steam boiler and heater provide the heat required to speed up the extraction process. The conveyor system allows for the easy transfer of the avocado fruits from one stage of the extraction process to another. The centrifuge helps to separate the oil from the pulp.



How to Operate Avocado Oil Production Line



Operating an Avocado Oil Production Line is simple and straightforward. Here is a step-by-step guide on how to operate the production line:



1. Cleaning and washing of the fruits

The first step is to clean and wash the avocado fruits to remove dirt and debris. This helps to ensure the quality of the extracted oil.



2. Slicing the fruits into small pieces

After washing, the fruits are sliced into small pieces using a slicer or a knife. This increases the surface area and makes it easier for the hydraulic press to extract the oil.



3. Crushing the fruits

The sliced pieces are then crushed using a hydraulic press, which applies pressure to extract the oil. The crushed pieces are placed in a container and transferred to the hydraulic press for extraction.



4. Separation of oil and pulp

The extracted oil is then separated from the pulp using a centrifuge. The centrifuge helps to remove any remaining pulp or contaminants from the extracted oil.



5. Packaging and storage

After separation, the extracted oil is then packaged into containers and stored in a cool and dry place. This helps to maintain the quality and freshness of the oil.



Conclusion



The application of Avocado Oil Production Line has revolutionized the process of extracting avocado oil. The modern technology used in the production line has made the extraction process faster, more efficient, and cost-effective. The production line ensures that the extracted oil is of high quality, pure, and free from impurities and contaminants. Operating the production line is easy, and the output is highly productive.



1. Avocado Bubble Washing Machine

Model

HT-QX200

Power

2.5kw

Voltage

220V 60HZ

Capacity

300kg/h

Dimension

2000*1000*1500mm

Weight

210kg



2. Avocado Pitting and Peeling Machine

Type

Name

Capacity

Power

(Kw)

Size

HT-MDJ2-4.0

Double channels denucleation beater

1.8T/h mango

4 T/h tomatoes or orange

7.5

1535*1420*1680

HT-MDJ2-5.0

Double channels denucleation beater

3T/h mango

5 T/h tomatoes or orange

15.0

1935*1650*1900



3. Avocado Oil Pressing Machine

Model

HT-YZ180

HT-YZ230

HT-YZ320

Dimension(mm)

800x650x1100

900x850x1550

1100x1000x1650

Weight

600kg

880 kg

1600 kg

Pressure

1600KN

2200KN

3000KN

Working pressure

60Mpa

60Mpa

60Mpa

Heater bands power

1KW

1KW

2KW

Heater bands temperature

70-100℃

70-100℃

70-100℃

Motor power

1.5KW

1.5KW

2.2KW

Voltage

220V/380V

220V/380V

220V/380V



4. Avocado Oil Concentrator

Model and specification

HT-NSJ200

HT-NSJ300

HT-NSJ500

Model and specification

Extraction tank

Volume(L)

250

375

550

Working pressure in the jacket(Mpa)

0.15

0.15

0.15

Working pressure in the container(Mpa)

≤0.09

Concentration tank

volume(L)

250

375

550

Vacuum degree in the tank(Mpa)

-0.08

Working pressure in the heater(Mpa)

0.09

Working reflux of heat reflux(L/H)

80

120

180

Vacuum pump

Electric voltage(V)

380

380

380



Motor(KW)

2.2

3

3

Water pump

Motor(KW)

0.75

0.75

0.75



Product Pictures



Avocado Cooking Oil Extractor
