Fruit Vegetable Washing and Drying Machine
2. The design of the production line is reasonable, which improves the work efficiency, is suitable for the assembly line operation, and improves the degree of enterprise production automation.
Introduction of fruit vegetable washing and drying machine
The fruit vegetable washing and drying machine is an automated equipment that integrates washing, draining and air-drying functions. It is widely used in fruit and vegetable processing plants, pre-prepared food production and other fields. It aims to efficiently remove stains, sand and residual water on the surface of fruits and vegetables, extend the shelf life and improve the efficiency of subsequent processing.
Bad fruit sorting machine (single layer)
The conveyor selection machine uses a food-grade PVC belt conveyor in the middle, a speed-regulating motor, stainless steel support plates on both sides, and a rotten fruit storage basket to facilitate the selection operation.
Fruit and vegetable cleaning machine (frequency conversion speed regulation)
The equipment is made of all stainless steel SUS304/2B material, which meets the requirements of food hygiene. The equipment is equipped with a bubble generating device to make the material tumble. It is the first choice for product cleaning. At the same time, an appropriate amount of medicine can be added to disinfect and fix the color. Floating objects can overflow from the overflow tank, and sediments can be discharged from the sewage outlet, achieving the purpose of cleaning. It has the characteristics of high cleaning rate, energy saving, water saving, stable and reliable equipment, etc.
Fruit and vegetable secondary cleaning machine (frequency conversion speed regulation)
The material enters the water tank and is fully broken up, rolled, cleaned and conveyed under the action of high-pressure water flow and strong bubbles. The mud and sand washed off the surface of the material sink into the isolation bin at the bottom, and will not be turned over and refluxed to cause re-contamination. The cleaned material is then sprayed and cleaned after being discharged from the water and sent to the next process.
Vibrating drainer
The high-frequency vibration generated by the vibration motor is used to shake the items placed on the drain basket or drain table, accelerating the separation of water from the items. At the same time, with the effect of gravity, the water can quickly flow away through the drain holes or gaps, thereby achieving the purpose of drainage.
Tumble dryer
The main body of the machine is made of SUS304 stainless steel, and the time is controlled by frequency conversion speed regulation. Through multiple turns to drain water, and high-pressure strong cold wind blowing from the upper part, water droplets on the surface of the material are effectively removed, which greatly shortens the preparation work of labeling and packing. It is suitable for assembly line operation and improves the degree of automation of enterprise production. The drying air temperature is normal temperature, which effectively protects the color and quality of the material itself. The product can completely achieve the effect of drying the surface water droplets (water between the wrinkles on the bag surface can also be dried).
product parameters
|
Power |
0.75kw |
|
Voltage |
380V/50Hz |
|
Belt width |
400mm |
|
Length |
4000mm |
|
Weight |
200kg |
product parameters
|
Mesh belt specification |
800mm |
|
Gear motor |
0.75kw |
|
running speed |
0-2300mm/min |
|
Wave blower |
2.2kw |
|
Conveying motor |
1.5kw |
|
Dimension |
6000*1200*1300mm |
|
Weight |
650kg |
product parameters
|
Mesh belt specification |
800mm |
|
Gear motor |
0.75kw |
|
running speed |
0-2300mm/min |
|
Wave blower |
2.2kw |
|
Conveying motor |
1.5kw |
|
Dimension |
6000*1200*1300mm |
|
Weight |
650kg |
product parameters
|
Length |
2000mm |
|
Power |
0.55kw*2 |
|
Dimension |
2000*900*1200mm |
|
Weight |
250kg |
product parameters
|
Reticulum belt |
800mm |
|
Gear motor |
Nmrv0.75-50 |
|
Motor shaft |
800# |
|
running speed |
0-2300mm/min |
|
Fan |
0.75kwx8set |
|
Thickness |
2mm |
|
Power |
6.75KW |
|
Voltage |
380V/50HZ |
|
Dimension |
4500*1200*1350mm |
FAQ
Q: 1.What's the MOQ?
A: 1 set
Q: 2. Can the machine be customized?
A: A: As a professional manufacturer, we can customize the machine according to your requirements, like capacity, material, color, voltage, logo, etc.
Q: 3.What's the payment term?
A: We accept the T/T, Western union or Alibaba Trade Assurance Payment, etc.
Q: 4.How to ship?
A: We have some long cooperation freight forwarder, they can help us ship the machine all over the world. Including sea, air, express, train, sea to the door is no problem.
Q: 5.Which port do you send the goods from?
A: Any Ports in China, such as Shanghai, Qingdao, Guangzhou and so on.
Q: 6. How long is the warranty of the machine?
A: Two years warranty.
Q: 7.How to buy this machine?
A: You could send us your company name and address ,then we draft proforma invoice ,you could pay to us via proforma invoice .
Q: What about the package?
A: Usually we will use the standard export wooden case.
Q: Do you need a supplier to provide transportation?
A: If need we ship help you,please leave your details address include zip code.
Q: 10.Are there any requirements for power supply?
A: We can according customer's need to customized 110v/220v/380v/440v etc.
Q: What about Pre-sale service:
A: A: Support voltage changing service as your demand; Support logo customizing ; Provide good solution for your project ; Testing and debugging before delivery ;
Q: What about After-sales service?
A: 12.Video technical support; Online support ; Field installation, commissioning and training;
