Intestine Scraping Machine
2. The Intestine Scraping Machine has the advantages of durability, convenient operation, high efficiency and low cost
4.It can effectively improve work efficiency, reduce labor intensity of workers and effectively reduce production costs. It is suitable for production and processing in large, medium and small sausage workshops.
Introduction of Intestine scraping machine
Intestine scraping machine which is is mainly used for processing pig intestines, and sheep intestines cleaning casings are used for sausage making.
The application of sausage washing machine: sausage scraping machine is mainly used for processing pig intestines, lamb intestines, cleaning casings, used for sausage production
Purpose: Mucosal Scraper.
Production process: Intestine scraping machine is mainly used for the processing procedure of pig and sheep small intestines
Advantages of intestinal scraping machine:
It can ensure that the fat film of pig intestines is not damaged (the fat film is an important part of the casing, which is a focus of the casing purchaser when accepting the casing). Scraping the sheep intestines will also not damage the fat film of the sheep intestines, completely solving the technical problem that the sheep intestines cannot be scraped with the scraping machine.
Structure composition
the equipment mainly includes base, motor, reducer, chain wheel and chain drive, belt pulley drive and casing scraping device
The motor and reduction gearbox are located at the bottom of the base, the casing scraping device is located at the top of the base, and the motor, reduction gearbox and casing scraping device are connected and driven by sprocket, chain, belt and pulley.
Working principle
the scraper is adjacent to the large rubber roll and is located at the oblique top of the large rubber roll, with a gap between them. It is only necessary to feed the small intestine of pigs and sheep into the gap between the big rubber roller and the scraper and the gap between the two small rubber rollers, and then the casings with reliable quality can be processed.
intestinal scraping machine parameters
|
Model |
HT-XCJ550 |
HT-XCJ750 |
|
Machine size |
1100*715*610mm |
1150*830*1300 |
|
Powder |
1.1kw |
1.5kw |
|
Voltage |
220v |
380v |
|
frequency |
50hz |
50hz |
|
Capacity |
200-300pcs/hour |
320-400pcs/hour |
|
Length of intestines |
Pig intestines：12-15m/Sheep intestines:50-60m |
|
|
Pull roll length |
55 |
75 |
|
Packing size |
1300*915*810mm |
1220*900*1450mm |
|
Net weight |
260kg |
340kg |
|
Gross weight |
285kg |
389kg |
|
Remark |
If the intestines is with much grease, better to use water at temperature of 30-40°C |
|
