Paper Drink Straw Machine
video

Paper Drink Straw Machine

The stainless steel paper drink straw machine integrates paper loading, gluing, rolling and cutting. It is equipped with a CNC multi-knife cutting system and can cut finished paper tubes online. It is suitable for producing various types and specifications of paper straws.
Send Inquiry
Product Introduction

Paper Drink Straw Machine is the latest new product developed by our company.

The Paper Drink Straw Machine integrates automatic paper splicing, roll forming, cutting and storage. It uses a CNC multi-knife system to directly produce finished straws. The straws produced by this machine can withstand high temperatures of 100 degrees (conventional paper straws can be up to 70 degrees), can also be composted and degraded, and have no pollution to the environment.

One of the biggest advantages of using the Paper Drink Straw Machine is that it is easy to operate and highly efficient. With minimal training, operators can produce large quantities of straws in a short amount of time, saving time and reducing labor costs. The machine also uses high-quality materials, ensuring that each straw produced is of top-notch quality.

Another key benefit of the Paper Drink Straw Machine is that it offers a sustainable solution to plastic pollution. Traditional plastic straws take hundreds of years to decompose, resulting in significant harm to marine life and ecosystems. Paper straws, on the other hand, decompose rapidly and do not harm the environment. By producing paper straws, businesses can contribute to a cleaner, greener planet and meet their sustainability goals.



Advantage:



1. Save space and time

⒉ The machine has its own sterilization function.

3. Eliminate trouble caused by weather and glue problems.

4. The finished straw is high temperature resistant and biodegradable.

5. Product loss rate is greatly reduced

6. For the same number of grams of raw materials, the hardness of the finished product increases.

7. The whole machine uses servo motors



Model

HT-ZX01

Internal diameter

4.5-12mm

Paper roll

2-3 plies

Thickness

0.25-1mm

Cutting length

120-820mm

Way of fixing shaft

clamp 5PICS

Production speed

10-40m/min(4-12)

Way of cutting

58*38*2mm circular cutting blade

Way of gluing

Single / double side

Blade

5 groups

Paper reel stand

6 plies T-bar 1 paper reel stand

Glue system

3 plies independent glue tank

Main motor

1.5kw*2

Inverter

1.5KW 4 KW Schneider

Servo motor

1.5KW Schneider

Control system

China

Way of scraping glue

Independent glue box/pol polyurethane scraping blade

Way of straws

Automatic

Oil

Automatically given

L-type pipe machine

China

Cutter motor

550W

Roller motor

550W

Gluing motor

550W

Belt

China

The electromagnetic valve

7PICS 24V

Fan

2PICS

cylinder

32*20 5PICS

Voltage

380V 50HZ

Operator

1-2 workers

Host size

3250*1100*1450MM

Occupied area

7200*4800*1500MM

Weight

1300kg
