Pomegranate Peeler Machine
2.The characteristic of the machine is the automatic separation of pulp, residue (skin, seeds, nuts), which can be combined on the production line for assembly line operation and can also be used for single machine production.
Machine features
The machine is made of 304 stainless steel.
01
Wide applicability, suitable for pomegranate, passion fruit, grapefruit, etc.
02
There is no damage to the seeds of the fruit.
03
Easy to operate and structurally simple.
04
Corrosion resistance and long service life.
05
The working principle of the Pomegranate Peeler Machine
The material enters the chamber through a crushing device and is then processed using a scraper and a sieve Achieve the separation of pomegranate flesh and skin.
Pomegranates enter the upper fruit breaking device from the feeding hopper. The upper fruit breaking device presses the pomegranate apart with a gap of 20 millimeters between the two rollers, and then enters the lower fruit breaking device. The lower fruit breaking device squeezes the pomegranate again with a gap of 10 millimeters between the two rollers. After two stages of squeezing, the pomegranate has basically separated its skin and flesh, and falls into the separation device. It is then stirred on the mixing shaft Under the stirring, the pomegranate flesh falls down from the sieve and the pomegranate peel is discharged from the tail. The upper and lower fruit breaking rollers are elastic structures with adjustable gaps. Pomegranate pulp and juice are transported to a dual channel pulping machine using a screw pump.
Contact now
In Conclusion
1.
Pomegranate Peeler Machine is one of the deep processing equipment for pomegranate, which is used for pre-treatment of pomegranate juice extraction. In addition to pomegranate peelers, Jierguge also provides pomegranate juicers, pomegranate juicers, pomegranate juice canning machines, etc., which can provide a complete set of pomegranate processing and production equipment, as well as a complete set of pomegranate production line mechanical solutions.
2.
Pomegranate Peeler Machine can produce up to 1 ton per hour, and the peeled pomegranate seeds are intact and can be directly processed for the next step. This machine processes pomegranate seeds one by one, using pure mechanical methods to remove coating and seeds. Made of stainless steel, it is easy to operate. By clicking the touch screen, the pomegranate is placed into the feeding port, and the machine automatically completes the extraction and seed separation. Fresh pomegranate seeds are continuously produced one by one.
comparison of product parameters
|
Model |
HT-BPJ1 |
HT-BPJ2 |
HT-BPJ20 |
HT-BPJ50 |
|
Capacity |
0.5t/h |
1t/h |
2t/h |
4-6t/h |
|
Power |
3kw |
5.5kw |
8.1kw |
12.1kw |
|
Voltage |
380v |
380v |
380v |
380v |
|
Dimension |
970*630*1180mm |
1000*720*1230mm |
2100*885*1900mm |
3000*1000*2300mm |
FAQ
Q: What's the MOQ?
A: 1 set
Q: Can the machine be customized?
A: As a professional manufacturer, we can customize the machine according to your requirements, like capacity, material, color, voltage, logo, etc.
Q: What's the payment term?
A: We accept the T/T, Western union or Alibaba Trade Assurance Payment, etc
Q: How to ship?
A: We have some long cooperation freight forwarder, they can help us ship the machine all over the world. Including sea, air, express, train, sea to the door is no problem.
Q: Which port do you send the goods from?
A: Any Ports in China, such as Shanghai, Qingdao, Guangzhou and so on.
Q: How long is the warranty of the machine?
A: Two years warranty.
Q: How to buy this machine?
A: You could send us your company name and address ,then we draft proforma invoice ,you could pay to us via proforma invoice .
Q: What about the package?
A: Usually we will use the standard export wooden case.
