Jacketed Pan
2.Jacketed Pan is widely used in the processing of foods such as candy, pharmaceuticals, dairy products, canned goods, and marinated foods.
3. Jacketed Pan generally has three heating methods: electric heating, steam and gas.
Zhengzhou Hento Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of jacketed pan in China. With abundant experience, we warmly welcome you to buy customized jacketed pan from our factory. For more cheap products, contact us now.
Machine Introduction
Jacketed Pan, also known as steam pot, steaming pot, or sandwich steam pot. The Jacketed Pan is widely used in the processing of sweets, pharmaceuticals, dairy products, alcohol, cakes, preserves, beverages, cans, marinades and other foods, and can also be used in large restaurants or canteens to cook soup, cook vegetables, stew meat, and make porridge. It is a good equipment for food processing to improve quality, shorten time, and improve labor conditions.
Structural principle
The Jacketed Pan Machine pot body is a double-layer structure composed of an inner and outer spherical pot body, and the electric heating Jacketed Pan is heated by injecting heat transfer oil into the middle layer as the medium. There are fixed, tilting, stirring and other appearance forms. The tilting Jacketed Pan can tilt 90 degrees to pour materials, and the pot is clean.
The capacity includes 50L, 100L, 200L, 300L, 400L, 500L, 600L, 800L, 1000L, etc. The motor power is 0.75-4Kw, and different power motors can be configured according to the material.
Machine classification
1. Divided by structural form: tilting Jacketed Pan, vertical (fixed) Jacketed Pan structure.
2. Divided by heating method: electric heating Jacketed Pan, steam heating Jacketed Pan, gas heating Jacketed Pan, electromagnetic heating Jacketed Pan.
3. Use mixing or non mixing equipment according to the process requirements.
4. Jacketed Pan can be divided into three types according to sealing methods: uncovered type, flat lid type, and vacuum type.
Machine advantages
This Multi Jacketed Pan, has a large heating area, high thermal efficiency, materials heat up fast, uniform heating and the heating temperature easy to control and so on.
Widely used in large hotels, guest houses, restaurants, industrial and mining enterprises, units, institutions canteens, as a boiled pond, step, cooking, cooking, and stepping of mean dumps, etc. For many years, major of users agree that this product is actually improving the product quality, shorter working hours, and better working conditions for excel Food equipment
comparison of product parameters
|
Model |
HT-JCG50 |
HT-JCG100 |
TH-JCG200 |
HT-JCG300 |
|
Capacity |
50L |
100L |
200L |
300L |
|
Electric Type Dimension |
1000*1500*850 |
1300*850*950 |
1600*950*1050 |
1650*1000*1050 |
|
Gas Type Dimension |
1050*1200*860 |
1450*1000*1050 |
1600*960*1300 |
1400*1160*1200 |
|
Steam Type Dimension |
1000*1500*850 |
1300*850*950 |
1600*950*1050 |
1650*1000*1050 |
|
Material |
SUS 304 |
SUS 304 |
SUS 304 |
SUS 304 |
|
Volume(m³) |
0.05 |
0.1 |
0.2 |
0.3 |
|
Mixing Speed |
25 r.p.m |
25 r.p.m |
25-36 r.p.m |
25-36 r.p.m |
|
Electric heating tube power |
9kw |
15kw |
12-15kw |
15-18kw |
|
Heating up time |
30min(Fill with water and heat up to 20-100 ℃) |
35min(Fill with water and heat up to 20-100 ℃) |
45min(Fill with water and heat up to 20-100 ℃) |
50min(Fill with water and heat up to 20-100 ℃) |
|
Tiltable angle |
95° |
95° |
95° |
95° |
|
Combustion engine specifications |
50000 kcal |
50000 kcal |
50000 kcal |
50000 kcal |
|
Voltage |
220V |
380V |
380V |
380V |
|
Machine Weight |
150kg |
185kg |
220kg |
260kg |
|
Model |
HT-JCG400 |
HT-JCG500 |
TH-JCG600 |
HT-JCG800 |
|
Capacity |
400L |
500L |
600L |
800L |
|
Electric |
1650*1200*1250 |
1700*1100*1150 |
1750*1250*1250 |
1850*1350*1500 |
|
Gas |
1550*1200*1250 |
1700*1300*1150 |
1850*1400*1350 |
2010*1400*1600 |
|
Steam |
1650*1200*1250 |
1700*1100*1150 |
1750*1250*1250 |
1850*1350*1500 |
|
Volume(m³) |
0.05 |
0.1 |
0.2 |
0.3 |
|
Heating up time |
30min(Fill with water and heat up to 20-100 ℃) |
35min(Fill with water and heat up to 20-100 ℃) |
45min(Fill with water and heat up to 20-100 ℃) |
50min(Fill with water and heat up to 20-100 ℃) |
|
Tiltable angle |
95° |
95° |
95° |
95° |
|
Combustion engine specifications |
50000 kcal |
50000 kcal |
100000 kcal |
100000 kcal |
|
Steam flow |
80kg |
100kg |
120kg |
150kg |
|
Voltage |
380v |
380v |
380v |
380v |
|
Machine Weight |
300kg |
350kg |
400kg |
520kg |
*In case of the machine upgrade, the appearance and size may be a little different, please take the actual machine as the standard.
