Arc Sprayer

Arc sprayer is an innovative and efficient method of applying coating onto metal surfaces. Using an electric arc to heat and melt wire feedstock, the process creates a fine mist of droplets that rapidly solidify onto the substrate, resulting in a uniform and durable coating.

Send Inquiry

Product Introduction

1. The arc sprayer is widely used in the aerospace, automotive, food, industrial and medical industries. In the aircraft industry, the equipment is often used to coat the engine parts and airframe components with materials that can withstand high temperatures. In the automotive industry, the equipment is used to apply a range of coatings including wear-resistant coatings, anti-corrosion coatings and decorative coatings. In the food industry, the equipment is used to coat processing equipment to prevent contamination and bacteria growth.

2. The working principle is simple. The device uses an electric arc that is generated by two wires that have been fed into the machine. The arc creates high heat that melts and atomizes the metal, which is then sprayed onto the substrate using a compressed air nozzle.

thermal arc spray machine

Common applications

(1). Corrosion protection

This technology is used to deposit high-quality coatings that protect metallic surfaces from corrosion, erosion, and wear in harsh environments.

(2). Thermal barrier coatings

The technology is the deposition of thermal barrier coatings for aircraft engines and gas turbines. The thermal barrier coatings are used to reduce the temperature of the metal substrate, which increases the lifespan of the machinery.

(3). Repair of worn parts

It is used in the repair of worn-out parts, such as pump casings, shafts, and drive systems. The technology is used to deposit a high-quality coating on worn-out parts, which restores them to their original condition.

(4). Aerospace industry

The technology is used to deposit coatings on aircraft components such as turbine blade tips, landing gear, fan blades, and many other components. These coatings improve the lifespan of aircraft components and reduce maintenance costs.

(5). Automotive industry

The machine can protect car bodies and parts from corrosion, wear, and tear. The technology is used to deposit coatings on brake drums, suspension components, exhaust systems, and other parts.

Model	HT-SX300	HT-SX400
OCV	DC 20-45 V	DC 20-45 V
Power	15.8KVA	18.8KVA
Voltage	AC 380V 50Hz 3phase	AC 380V 50Hz 3phase
Load rate	60% (300A)	60% (400A)
Insulation grade	E	E
Pressure	≧0.6 MPa	≧0.6 MPa
Dimension	7005001010mm	7005001010mm

Model	HT-SX600A	HT-SX600B
OCV	DC 20-45 V	DC 20-45 V
Power	32.6KVA	32.6KVA
Voltage	AC 380V 50Hz 3phase	AC 380V 50Hz 3phase
Load rate	60% (400A)	60% (400A)
Insulation grade	E	E
Pressure	≧0.6 MPa	≧0.6 MPa
Dimension	7005001010mm	7005001010mm
