Industrial Garden Sprayer
2.It is also suitable for spraying water for dust prevention, dust removal, dust suppression, and cooling in environmental protection industries.
The industrial garden sprayer is mainly composed of air outlet, nozzle, electrical box, stainless steel centrifugal pump, air inlet, host machine and chassis.
The main selling points of the industrial Garden Sprayer are:
1. Aluminum-magnesium alloy fan. The aluminum-magnesium alloy fan is intelligently controlled, powerful, has high range and wide coverage area.
2. Stainless steel water ring. The nozzle is adjustable and uses a stainless steel ring head, which is convenient and durable.
3. Remote control system. The photoelectric integrated remote control system uses brand-name electric boxes and integrated circuits to ensure a safer working environment (electricity and lighting are together).
4. The gun barrel rotates at multiple angles. The nozzle can be flexibly adjusted, with a horizontal rotation angle of 320 degrees and a tilt angle of 70 degrees.
5. PLC centralized control module. Electrical appliance brand, the first national standard brand for all components of electrical boxes, ensuring safety.
6. Intelligent control. Remote control, one-button start, free your hands. Mobile phone and computer standby control. Similarly, the industrial Garden Sprayer has multiple power sources: a variety of power options, available with 380V. Three applicable scopes: metallurgical steel, coal chemical plants, thermal power plants, port coal yards, stone quarries, fully enclosed stockyards, natural disaster areas, and garbage dumps. , open-air shelves for mining products, etc.
|
Model |
3PW-20 |
|
Horizontal range |
20 |
|
Horizontal angle |
0-320 degree |
|
Back leaning angle |
-10-40 degree |
|
Max. covered area |
800㎡ |
|
Work pressure |
0-3.5 MPa |
|
Spray particle size |
50--200 um |
|
Insulation grade |
IP55 |
|
Total installating power |
6KW |
|
Control mode |
Manual/remote |
|
Fan power |
2.2kw |
|
Air pressure |
2840pa |
|
Air quantity |
8800m³/h |
|
Size |
1200*900*1700mm |
|
Spray head quantity |
8 pieces |
|
Voltage |
AC380\50HZ |
|
Motor power |
8kw |
|
Water pump power |
3kw |
FAQ
Q1: What's the MOQ:
A: 1 set
Q2: Can the machine be customized?
A: As a professional manufacture, we can customize the machine according to your requirements, like capacity, material, color, voltage, logo, etc.
Q3: What's the payment term?
A: We receive the T/T, Western union or Alibaba Trade Assurance Payment, ect.
Q4: How to ship?
A: We have some long cooperation freight forwarder, they can help us ship the machine all over the world. Except sea, air, express, sea to the door is no problem.
Q5: Which port do you send the goods from?
A: Shanghai, Qingdao, Shenzhen or other port.
Q6: How long is the warranty of the machine?
A: Two years warranty
