Drying Oven

1.Drying Oven (also known as a drying cabinet or oven) is a "large cabinet" capable of precisely controlling temperature. 2.It heats through electric heating elements and, in some types, uses a fan to circulate warm air, ensuring even heating of items inside the chamber for purposes such as drying, baking, sterilization, or heat treatment. 3.Product Capacity: 100kg/batch

Send Inquiry

Product Introduction

Drying Oven Introduction

1.

Box body: Typically consists of an outer shell, inner lining, and an insulating layer in between. The outer shell provides support and protection,the inner lining is often made of corrosion-resistant stainless steel. The insulating layer (such as ceramic fiber) effectively reduces heat loss.

2.

Heating System: The core component is an electric heating wire or resistance band, it generates heat upon electrification and serves as the "heat source" for the drying oven.

3.

Blower System (for certain types): Composed of a motor and fan, it forcibly drives air convection within the chamber through specially designed air ducts. This is crucial for achieving uniform temperature inside the chamber.

4.

Control system: It can be seen as the "brain" of the drying oven. It includes temperature sensors (such as Pt100 platinum resistors) and intelligent temperature controllers (such as PID controllers) for precise temperature setting, control, and display. Meanwhile, an important safety device - the over temperature protector - will forcibly cut off the power supply when the temperature loses control, ensuring safety.

modular title

Drying of fruits and vegetables

This process is actually achieved by circulating hot air to evenly remove moisture from the fruits and vegetables. It should be noted that the temperature should not be too high, otherwise it is easy for the outside to dry and the inside to get wet, or for fruits and vegetables to be "roasted" instead of "dried".

Dog food drying

Whether it's drying homemade wet food or trying to make damp dry food crispy again, the principle is the same. However, it is important to ensure that the interior of the drying oven is clean and hygienic. It is best to dry it separately to avoid cross contamination or cross contamination.

Black garlic making

This is the most special usage. It utilizes a continuous low-temperature maturation process, rather than simple "drying". So it is necessary to seal the garlic (such as putting it in a sealed jar) in order to retain its own moisture and gradually turn black and soft over prolonged heating. This process usually takes several weeks and requires some patience.

Contact now

Daily maintenance of drying oven

Keep the equipment clean and avoid using it in corrosive environments containing acid and alkali.

Handle with care during transportation to prevent internal electrical circuits from becoming loose.

If there is a malfunction (such as not heating up), check whether the heating wire is burnt out or whether the connector is loose. For complex circuit problems, it is recommended to seek professional maintenance.

comparison of product parameters

Model	HT-HGX100	HT-HGX300	HT-HGX500
Capacity	100kg/batch	300kg/batch	500kg/batch
Power	4KW	10KW	10KW
Voltage	220V/380V	220V/380V	220V/380V
Drying temperature	100 degrees(adjustable)	130 degrees (adjustable)	/
Dimension	135011002300mm	300018002300mm	500022002300mm
Weight	300kg	350kg	1500kg

*In case of the machine upgrade, the appearance and size may be a little different, please take the actual machine as the standard.

If you have specific drying needs (such as which material to dry, required temperature range, etc.), please let me know and I can recommend a more suitable type of drying oven for you.

FAQ

Q: Can the machine be customized?

A: As a professional manufacturer, we can customize the machine according to your requirements, like capacity, material, color, voltage, logo, etc.

Q: How to ship?

A: We have some long cooperation freight forwarder, they can help us ship the machine all over the world. Including sea, air, express, train, sea to the door is no problem.

Q: Which port do you send the goods from?

A: Any Ports in China, such as Shanghai, Qingdao, Guangzhou and so on.

Q: How long is the warranty of the machine?

A: Two years warranty.

Q: What's the payment term?

A: We accept the T/T, Western union or Alibaba Trade Assurance Payment, etc.

Q: How to buy this machine?

A: You could send us your company name and address ,then we draft proforma invoice ,you could pay to us via proforma invoice .

Q: Are there any requirements for power supply?

A: We can according customer's need to customized 110v/220v/380v/440v etc.

Q: What about the package?

A: Usually we will use the standard export wooden case.
