Chicken Feed Pellet Making Machine

The Chicken Feed Pellet Making Machine adopts the mold plate, and the pressure roller is specially treated with alloy steel. Under the action of friction, the main shaft and the flat die drive the pressure roller to rotate. The bottom is discharged from the die hole, and the particles are sent out of the machine through the throwing tray, and the length of the particles can be controlled by adjusting the angle of the cutter.





1. Processed feed is easy to store:

Powdered feed and grass powder can be processed without adding or adding a little liquid, which greatly reduces the moisture content of pelleted feed and is convenient for storage.



2. The thickness of processed feed can be adjusted:

The diameter of the grinding hole is 3~5mm, the size is adjustable, and the length is also adjustable. Grass powder granules, grain granules and mixture granules can all be processed.



3. Durable and low noise:

The paint surface is sprayed/baked in a dust-free workshop, which is not easy to fall off, simple in structure, wide in applicability, small in floor space, and low in noise.



4.Machine has wide applicability

Soybean meal, grain, straw, green feed, meat and bone meal, whey powder, oil, fish meal, miscellaneous meal, etc. can be processed and produced, and poultry, livestock, and pet feed can be processed (pig feed, cattle feed, sheep feed, fish feed, chicken feed, etc.) feed, duck feed, goose feed, etc.)





Operating machine requires a few simple steps. Here is a general guide to follow:

1. Raw Materials Preparation: Before starting the machine, prepare the raw materials by cleaning them and cutting them into manageable pieces.

2. Turn on the Machine: Turn on the feed pellet machine to begin the pelleting process.

3. Feeding the Raw Materials: Begin feeding the raw materials into the machine. It's important to follow the recommended feeding rate to prevent overloading the machine.

4. Adjusting the Cutter: As the pellets are being formed, adjust the cutter to the desired size.

5. Collecting the Pellets: Once the pellets are formed, collect them in a container and store them in a cool, dry place





Model	HT-WX125	HT-WX150	HT-WX160	HT-WX210	HT-WX260
Capacity	60-80kg/h	90-150kg/h	120-180kg/h	200-300kg/h	500-600kg/h
Voltage	380v/220V	380V/220V	380V/220V	380V	380V
Power	4kw	4.5kw	4.5kw	10kw	15kw
Dimension	720*210*650mm	850*310*780mm	850*310*780mm	1100*450*930mm	1240*530*1190mm
